Air data
calibration
7750i Air Data Calibrator
Air data test set with unequalled
precision and long term stabil-
ity and superior pressure control
technology.
• High accuracy, RVSM compliant
• Accuracy to ± 2 feet,
0.02 knots
• True differential sensor for
airspeed (Qc)
RPM4-AD Reference
Pressure Monitor
Specialized pressure indicator
for the absolute and differen-
tial pressure ranges in air data
instruments.
• Fixed wing and rotary wing
range versions
• True Pt, Ps, Qc operation
2468A Pitot/Static
Primary Standard
Gas piston gauge specialized for
air data absolute and differential
pressure ranges.
• Pressure range: 0.4inHg to
103inHg
• Optional range: 3.4inHg to
400 inHg
• Accuracy to ± 0.5 feet,
0.003knots
• Extended mass set covers
entire air data range without
the need to change pistons
• Compatible with WinPrompt
and COMPASS software
7750i
RPM4-AD
2468A
Pressure
calibration
systems
7250sys Multi-Range
Pressure Calibration System
Turn-key automated gas pressure
calibration system.
• Gas pressure measurement and
control from low absolute to
17 MPa (2500 psi)
• Fully integrated multi-range
pressure test and calibration
systems with a single interface
and single test port
• Select either an 8 range or the
12 range system for maximum
performance and coverage
Custom Pressure
Calibration Systems
Engineered custom systems inte-
grate standard Fluke Calibration
products into a complete system
based on the user’s specific
requirements. These are often
multi-range systems that include
pressure generation and sup-
ply accessories, data acquisition
hardware and software and/or
test instrument connection mani-
folds. Custom systems include
but are not limited to turn-key
pressure calibration rack systems,
portable calibration carts and
automated pressure calibration
bench systems.
7250sys
38
www.flukecal.comPressure calibration
