Fluke 62 MAX Calibration Information

Infrared Thermometer
Performance Verification Tests
7
To prepare the Unit Under Test (UUT) for verification:
1. Visually inspect the UUT outer case for cracks or damage.
2. Open the battery compartment and inspect the battery and battery compartment for corrosion or damage.
3. Install a new AA battery prior to verification.
4. Close the UUT battery compartment door.
5. Set the UUT temperature units for degrees Celsius (°C) if necessary.
6. Push SEL until °C alone is shown. Change by pushing SET.
Performance Verification Test Procedures
Note
The subsequent verification test requires the blackbody emissivity to be set to 0.95 at all
temperature points.
Note
For temperatures below ambient, to reduce the chance of condensation or ice buildup on the
emitter plate of the 4180, it is recommended to install a clean dry air or nitrogen gas purge
box on the front of the 4180 Blackbody. Although the purge box is recommended, it is optional.
If temperature measurements are made without a purge box, refer to the 4180 User Manual
for how to make proper temperature measurements below ambient. See Figure 3.
hiy003.eps
Figure 3. Aim the 62 Max + for Verification

Fluke 62 MAX Specifications

General

Type	Infrared environment thermometer
Purpose	Outdoor
Placement	Hand
Display type	Digital
Product color	Yellow
Display form factor	Rectangular
International Protection (IP) code	IP54
Accuracy	1 °C
Response time	500 ms
Spectral response	8 - 14 µm
Min/Max temperature memory	Yes
Temperature measurement range	-30 - 500 °C
Temperature measurement units	F, °C
Certification	EN 61326-1:2006 EN 61326-2:2006 EN/IEC 61010-1: 2001 EN 60825-1 Class II
Battery type	AA
Power source	Battery
Number of batteries supported	1
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Battery life	10 h

Weight and Dimensions

Depth	75 mm
Width	85 mm
Height	175 mm
Weight	255 g
