Parts and Schematics
Parts Lists, Drawings, and Schematics
4
4-7
Table 4-4. A1 Main PCA
Reference
Fluke
Stock Total Quantity
Designator Description Number 7-300 7-600 12B 18
C1 CAP, TA, 0.47 µF, ±20%, 35V 655035 1 1 1 1
C2, C5-7 CAP, POLYES, 0.022 µF, ±10%, 50V 715268 0 0 4 4
C2, C7 CAP, POLYES, 0.022 µF, ±10%, 50V 715268 2 2 0 0
C3 CAP, TA, 22 µF, ±20%, 6V, 6032 876545 1 1 1 1
C4, C13 CAP, CER, 0.1 µF, ±10%, 25V, X7R, 1206 747287 0 2 2 0
C4, C12, C13 CAP, CER, 0.1 µF, ±10%, 25V, X7R, 1206 747287 3 0 0 0
C4, C11, C13 CAP, CER, 0.1 µF, ±10%, 25V, X7R, 1206 747287 0 0 0 3
C5, C6 CAP, CER, 4700 PF, ±20%, 100V 743427 2 2 0 0
C8 CAP, TA, 3.3 µF, ±20%, 16V, 3528 876552 1 1 1 1
C9 CAP, CER, 0.022 µF, ±10%, 50V, X7R, 1206 747279 1 1 1 1
C10 CAP, AL, 22 µF, ±20%, 10V, SOLV PROOF 887245 1 1 1 1
C14 CAP,POLY,.01 µF, ±10%,.1000V 822361 1 1 1 1
C15 CAP, TA, 47 µF, ±20%, 10V, 7343 867580 1 1 1 1
C16 CAP, CER, 10 PF, ±20%, 50V, C0G 721589 1 1 1 1
CR1 DIODE, SI, 100 PIV, 1 AMP, SURFACE MOUNT 912451 1 1 1 1
CR2 DIODE,SI,DUAL, BV = 50V, IO = 100 mA, SOT-23 851659 1 1 1 1
CR3 DIODE,SI, BV = 70V, IO = 50 mA, DUAL, SOT-23 742320 1 1 1 1
E1 SURGE PROTECTOR,3750v,±20% 867361 1 1 1 1
J1, J2 RECEPTACLE, INPUT 878988 2 2 2 2
LS1 AF TRANSD, PIEZO, 20MM 876995 1 1 1 1
Q1 TRANSISTOR, SI, NPN, SELECT IEBO, SOT-23 821637 1 1 1 1
Q2 TRANSISTOR, SI, PNP, SELECT ICER, SOT-23 887179 1 1 1 1
R1 RES, CERM, 162K, ±1%, .125W, 100 PPM, 1206 876198 1 1 1 1
R2 RES, MF, 332K, ±1%, 0.125W, 100 PPM 655217 1 1 1 1
R3 RES, MF, 23.4K, ±0.1%, 0.125W, 100 PPM 876292 1 1 1 1
R4 RES,VAR,CERM,25K, ±25%,.2W 876300 1 1 1 1
R5 RES, CERM, 43.2K, ±1%, .125W, 100 PPM, 1206 887109 1 1 1 1
R6 RES, CERM, 226K, ±1%, .125W, 100 PPM, 1206 876524 1 1 1 1
R7-9, R23, R28 RES, CERM, 1M, ±1%, .125W, 100 PPM, 1206 836387 5 5 5 5
R10 RES, CERM, 309K, ±1%, .125W, 100 PPM, 1206 876201 1 1 1 1
R11, R12 RES, MF, 30.1K, ±0.1%, 0.125W, 100 PPM 887161 2 2 2 2
R13 RES, MF, 27.1K, ±0.1%, 0.125W, 100 PPM 876289 1 1 1 1
R14, R15 RES, CERM, 10K, ±5%, .125W, 200 PPM, 1206 746610 2 2 2 2
R16, R18 RES,CERM, 470, ±5%,3W 887117 2 2 2 2
R17 RES,CERM, 1M, ±5%,1W 912589 1 1 1 1
R19 RES, MF, 450, ±10%, 107398 1 1 1 1
R21 RES JUMPER, 0.02, 0.25W 682575 1 1 1 1
R22, R29, R30 RES, CERM, 300, ±5%, .125W, 200 PPM, 1206 746362 3 3 3 3
R24 RES, CERM, 487K, ±1%, .125W, 100 PPM, 1206 887112 1 1 1 1
R25 RES, CERM, 2.2M, ±5%, .125W, 200 PPM, 1206 811778 1 1 1 1
To Next Page
