12B/18/7 Series
Service Manual
4-8
Table 4-4. A1 Main PCA (cont)
Reference
Fluke
Stock
Total Quantity
Designator Description Number 7-300 7-600 12B 18
R26 RES, CERM, 100K, ±1%, .125W, 100 PPM, 1206 769802 1 1 1 1
R27 RES, CERM, 0, +.05 MAX, .125W, 1206 810747 1 1 1 1
RT1 THERM, POS 1.1K, ±20%, 25C 867192 1 1 1 1
S1 SWITCH, SLIDE, 3 POS, 5 PIN 868117 1 1 1 1
U1 ARTIC, ASSEMBLY TESTED 858472 1 1 1 1
U2 IC, CMOS, 4 BIT MPU, LCD 601575 1 1 0 0
U2 *IC, CMOS, 4 BIT MPU, LCD CNTRLR, 80PNQFP 866913 0 0 1 1
VR1 IC, 1.23V, 150 PPM T.C., BANDGAP V. REF 634451 1 1 1 1
XBT, XBT2 CONTACT, BATTERY 890327 2 2 2 2
Y1 RESONATOR, CERAMIC, PIEZOELEC, 2.10
MHZ
876024 1 1 1 1
Z1 RES NET THK FILLM TESTED 872234 1 1 1 1
