Pressure Calibrator
Parts
13
Parts
Replacement parts are listed in Table 5. These parts can be ordered by contacting Fluke. Refer to the Users Manual for a
complete list of user-replaceable parts.
Table 5. Parts
Item Description Part/ Mod. No. Qty
AC72
Alligator clip red
Alligator clip black
1670641
1670652
1
1
BT1, BT2 9 V battery, ANSI/NEDA 1604A or IEC 6LR61 614487 2
Holster Holster, Yellow 664182 1
H2, 3, 4 Case screw 832246 3
H5, 6 Battery door fasteners 948609 2
H7, 8 Bracket screw 641131 2
MP1 LCD bezel, 718 30G 664158 1
MP1 LCD bezel, 718 100G 664169 1
MP1 LCD bezel, 718 1G 2545047 1
MP1 LCD bezel, 718 300G 2545058 1
MP2 LCD 686482 1
MP3, 4 Pump retainer bracket 664201 2
MP5 Gasket 664208 1
1G pump 2571725 1
MP6
30G, 100G and 300G pump 2558508 1
