Fluke 74X Series User Manual

Replaceable Parts
35
Replaceable Parts
Table 19 lists the customer replaceable parts. Replacement parts can be ordered from the
Fluke Corporation and its authorized representatives by using the part number under the
heading Part Number column. In the U.S., order directly from the Fluke Parts Dept. by
calling 1-888-993-5853. Parts price information is available from the Fluke Corporation
or its representatives. Prices are also available in a Fluke Replacement Parts Catalog
which is available on request.
In the event that the part ordered has been replaced by a new or improved part, the
replacement will be accompanied by an explanatory note and installation instructions, if
necessary.
Table 19. Replacement Parts
Designator Description Part Number Notes
A20
PCA, KEYBOARD
202389
1,2,3,4
A31 PCA, POWER SUPPLY 606738 1,2,3,4
A31 PCA, POWER SUPPLY 662798 5
A32 PCA, MAIN 606886 1,2
A32 PCA, MAIN 202496 3,4
A32 PCA, MAIN 202371 5
A33 PCA, I/O, CONNECTOR 662806 5
A34 PCA, I/O 606753 1,2
A34 PCA, I/O 202520 3,4
A34, J4 CABLE ASSY, PCB INTERFACE 662855 5
A35 PCA, THERMAL 606761 1,2,3,4
A35 PCA, THERMAL 662814 5
B1 BATTERY, LITHIUM, 3.0V, 0.18AH 929369
J7 JACK, BAT.ELIM., 2.54 MM, PIN 942730 5
J4 CABLE ASSY,FLAT,20COND,2ROW 107463
MP3 TOP CASE, YELLOW/GREY 202421
MP4 BOTTOM CASE, YELLOW/GREY 202439
MP6 LENS /DECAL 606894 1
MP5 LENS /DECAL 606902 3
MP7 LCD MODULE, 240X200,TRNSF 944967 1,3
MP7 LCD MODULE, 240X200 GRAPH TRANSMISSIVE 602430 2,4,5
MP8 BATTERY DOOR 938357
MP10 SIDE PLUG
(
MOLDED RUBBER
)
938274
MP11 KEYPAD
(
MOLDED RUBBER
)
606910 1,2,3,4
1. Used on 741 onl
y
2. Used on 741B onl
y
3. Used on 743 onl
y
4. Used on 743B onl
y
5. Used on 744 onl
y
