High-Pressure Modular Controller
Controller Settings (Setup Menu)
19
Table 5. Instrument Settings Menu
Tab Description
Language
Changes the UI language. Touch the Language tab to select English, Italian,
Spanish, Russian, Portuguese, Simplified Chinese, German, Japanese,
French, Korean, Czech, or Slovak. From Main menu, hold the Unlock button for
3 seconds and the system goes to the Language Selection menu.
Date/Time
Sets the date and time. Use MM/DD/YYYY, DD/MM/YYYY, or YYYY-MM-DD (M=
Month, D=Date, Y=Year). To change the format of the date, touch the Format tab,
select the format and touch Exit.
To change the date and time, touch the parameter to change (Month, Day, Year)
and use the keypad on the right to key in the new value. Push ENTER to store the
value(s).
Display
Adjusts the aspects of the Display. Touch the Display tab to get to the Brightness
and Screen Timeout parameters. For display brightness, touch Brightness tab
and use the keypad on the front of the Product to adjust the percentage. The
screen can also be set to turn off (timeout) after a certain amount of time. Touch
the arrow on the Screen Timeout tab and select 1, 5, 10, 15, 30 minutes, or
Never.
Decimal
Specify a decimal separator for your region, either “.” or “,”. To change the
separator, touch the Decimal tab.
Screen
Capture
The Product can save up to 5 screen captures. You can copy screen captures
from the product using a USB memory stick in the USB A port. Push and hold the
0 button on the keypad to capture the screen. Touch the Screen Capture tab to
enter the menu. From this menu, use the Next button to view existing screens, or
delete with the Delete or Delete All buttons.
Clear All Files
When you push Clear All Files tab, you are prompted for the password. Once you
enter the correct password, any screen capture files will be erased.
