Error Codes
If an error occurs during Product operation or control, an error message is shown
on the display. Errors can be caused by:
Incorrect control that uses the front panel, (for example, attempts to force a
prohibited mode or overloading of output terminals)
Product fault.
These messages are shown in Table 20. All error messages are shown in a
frame that overlaps the main screen. Alternately, error messages can be read
and cleared over the remote interface using the SYST:ERR? command. If the
error is slot or sensor specific, an additional number may be appended to the
reply.
Table 20. Error Codes
Error Number Error Message
0 No Error
103 Invalid Separator
104 Data Type
109 Missing Parameter
110 Command Header
113 Command Unknown
114 Header Suffix
201 Remote Required
221 Settings Conflict
222
Out of Range, Setpoint is above or below the Safety Limits of the controller, or the
Range of the active module.
281 Cannot create program
282 Illegal Program Name
284 Program Currently Running
285 Program Syntax Error
286 Program Runtime Error
313 Calibration Data Lost
315 Configuration Data Lost
330 Self-Test Failed
350 Queue Overflow
400 Query Error
500 Controller Malfunction
501 High Limit Exceeded, Pressure is above Safety Upper Limit
502 Low Limit Exceeded, Pressure is below Safety Lower Limit
503 Slew Limit Exceeded
