High-Pressure Modular Controller
PM500 Absolute Zeroing
45
Metering Valve
Vacuum Reference
To Process/DUT
To Vacuum Pump
Vacuum Pump
Test Port
ifb034.eps
Figure 10. Zero by Vacuum Setup
