Fluke 9103 - Maintenance

35
8 Digital Communication Interface
Interface Commands
Command Description
Command
Format
Command
Example Returned
Returned
Example
Acceptable
Values
Read R0 calibration parameter r[0] r r0: 999.999 r0: 100.578
Set R0 calibration parameter to
n r[0]=n r=100.324 90 to 110
Read ALPHA calibration
parameter
al[pha] al al: 9.9999999 al: 0.0038573
Set ALPHA calibration parameter
to
n
al[pha]=n al=0.0038433 .002 to .005
Read DELTA calibration
parameter
de[lta] de de:9.99999 de: 1.507
Set DELTA calibration parameter de[lta]=n de=1.3742 0–3.0
Read BETA calibration parameter be[ta] be be:9.999 be:0.342
Set BETA calibration parameter be[ta]=n be=0.342 –100.0 to 100.0
Functions not on menu
Read firmware version number *ver[sion] *ver ver.9999,9.99 ver.9103,2.00
Read structure of all commands h[elp] h list of commands
Read all operating parameters all all list of parameters
Legend: [] Optional Command data
{} Returns either information
n Numeric data supplied by user
9 Numeric data returned to user
x Character data returned to user
Note: When DUPLEX is set to FULL and a command is sent to READ, the command is returned followed by a
carriage return and linefeed. Then the value is returned as indicated in the RETURNED column.
Table 2 9103 Controller Communications Commands continued
