DSX CableAnalyzer
Users Manual
24
About Link Interface Adapters
Link interface adapters let you connect the DSX CableAnalyzer to
different types of twisted pair links. Figure 8 shows how to attach
and remove adapters.
Caution
To prevent damage to the cables on the permanent
link adapters and to make sure your test results are
as accurate as possible, do not twist, pull on, pinch,
crush, or make kinks in the cables. See Figure 9 on
page 25.
GPU109.EPS
Figure 8. How to Attach and Remove Link Interface Adapters
