DSX CableAnalyzer
Users Manual
34
AC Wire Map
The AC Wire Map test lets you do tests on links connected
through midspan PoE (Power over Ethernet) devices. See
the Technical Reference Handbook.
When the AC Wire Map test is on, this icon shows on the
home screen:
Note
Always turn off the AC wire map test when you
will not do tests through a PoE device. The AC
wire map test increases the time for an
Autotest.
Table 2. Settings for Twisted Pair Tests (continued)
