DSX CableAnalyzer
Users Manual
50
HEJ24.EPS
Figure 22. RESULTS Screen
The name of the active project.
: The number of results that passed. This includes individual
results for each ID and tests that have an result.
: The number of results that failed. This includes individual
results for each ID.
: The number of results that have measurements within the
range of accuracy uncertainty for the tester. See “PASS*/FAIL*
Results” on page 40.
C
E
A
B
F G
H
J
D
