DSX CableAnalyzer
Users Manual
74
GPU116.EPS
Figure 27. How to Connect Units Together to Update the Software
Type A USB port
Micro-AB USB
port
Type A USB port
Micro-AB USB
port
Updated main
unit
Updated main
unit
AC
adapter
AC
adapter
AC
adapter
AC
adapter
Remote
Main unit
