Expert Series Thermal Imagers
Detailed Specifications
51
Detailed Specifications
TiX500 TiX520 TiX560 TiX580
Temperature Measurements
Temperature Range (not
calibrated below -10 °C)
-20 °C to +650 °C -20 °C to +850 °C -20 °C to +1200 °C -20 °C to +800 °C
Accuracy ±2 °C or 2 % (whichever is greater) at 25 °C ambient
Imagining Performance
Image Capture Frequency 9 Hz or 60 Hz refresh rate depending on model variation
Detector Resolution 320 X 240 640 X 480
SuperResolution 640 X 480 1280 X 960
Thermal Sensitivity (NETD)
≤0.05 °C at 30 °C
target temp (50 mK)
≤0.04 °C at 30 °C
target temp (40 mK)
≤0.03 °C at 30 °C
target temp (30 mK)
≤0.05 °C at 30 °C
target temp (50 mK)
Total pixels 76 800 307 200
Infrared spectral band 7.5 μm to 14 μm (long wave)
Digital Zoom 2X, 4X 2X, 4X, 8X
IR-Fusion Technology
Autoblend mode
100 %, 75 %, 50 %, 25 % IR plus full visible
on camera
Continuously variable
Picture-in-Picture 100 %, 75 %, 50 %, 25 % IR
Visual (Visible Light) Camera
Type Industrial performance 5.0 MP
Parallax alignment with
standard IR lens
From ~60 cm (~24 in) to infinity
Standard Infrared Lens
Field of View (H X V) 24 ° x 17 ° 34 ° x 24 °
Spatial Resolution (IFOV) 1.31 mRad 0.93 mRad
Minimum Focus Distance 15 cm (∼6 in)
IR-Fusion Autoblend Picture-in-Picture and Full screen
Optional 2X telephoto smart lens
Field of View (H X V) 12 ° x 9 ° 12 ° x 8.5 °
Spatial Resolution (IFOV) 0.65 mRad 0.33 mRad
Minimum Focus Distance 45 cm (∼18 in)
IR-Fusion blending Picture-in-Picture and Full screen
Optional 4X telephoto smart lens
Field of View (H X V) 6.0 ° x 4.5 °
NA
Spatial Resolution (IFOV) 0.33 mRad
Minimum Focus Distance 1.5 m (∼5 ft)
IR-Fusion blending Picture-in-Picture and Full screen
