Acoustic Imager
Hand Strap/Neck Strap
7
Hand Strap/Neck Strap
The Imager includes a hand strap and a neck strap that makes it
easy to hold and operate as you take measurements. See Figure 2
for information about setup.
Figure 2. Hand Strap/Neck Strap
Display
The color display is a touchscreen that shows the test area as a
visual image combined with a sound image. See Table 3.
With the touchscreen you are able to set up and adjust all the test
parameters. For more information, see Basic Operation.
Table 3. Touchscreen
Item Description
Tool Menu
Capture Mode
Frequency Range of Spectrum
Palette of dB SPL Scale
Profile Selection (when enabled)
Folder Selection
Time/Date Stamp
Battery Status
To Next Page
