MICROMAPPER
TM
ENGLISH - 7
Appendix A
Connectors
M
ICROMAPPER main unit: RJ 45 jack
Remote Identifier: RJ 45 jack
Pairs tested
1 - 2, 3 - 6, 4 - 5, 7 - 8, and shield
LED Display
Horizontal: 5 green LEDs for pairs and shield display (1 - 2,
3 - 6, 4 - 5, 7 - 8, and SHIELD)
Vertical: 6 red LEDs (TONER, SHORT, REVERSED,
MISWIRE, SPLIT PAIRS, and LOW BATTERY)
Cables test limit
Minimum: 15.75" (40cm); Maximum:656' (200 m)
Power
M
ICROMAPPER: 6V alkaline DC battery (not included), Battery:
e.g. DURACELL PX28A, Varta VA034PX, Kodak K28A, and
Maxell, Panasonic and Toshiba #4LR44, or 6V Lithium
Battery: e.g. DURACALL PX 28L, Varta V28PXL, Kodak
K28L
Remote Identifier: No battery required
Dimensions
M
ICROMAPPER: 4.92" x 2.05" x 1.54"
125 mm x 52 mm x 39 mm
Remote Identifier: 1.87" x 1.12" x 0.87"
47mm x 28mm x 22mm
Weight
M
ICROMAPPER w/ Remote Identifier: 125 g
CAUTION: DO NOT DROP OR GET THE UNIT WET. DO NOT EXPOSE
MICROMAPPER TO EXTREME HUMIDITY OR DIRECT SUNLIGHT.
