ProcessMeter
Getting Acquainted with the Meter
9
Table 3. Rotary Switch Positions for Measurements
No. Position Function(s) Pushbutton Actions
A OFF
Meter off
B V A
Default:
measure ac V
F
Frequency counter
M Selects a MIN, MAX, or AVG action (see pg. 18)
KSelects a fixed range (hold 1 second for auto range)
I Toggles TouchHold
C Toggles relative reading (sets a relative zero point)
C d V
Measure dc V Same as above
D d mV
Measure dc mV Same as above
E O
Default: measure Ω
T for continuity
BLUE D test
Same as above, except diode test has only one range
F mA A L
High test lead in
cA: measure A dc
BLUE selects ac
High test lead in
dmA: measure mA
dc
Same as above, except there is only one range for each input jack
position, 30 mA or 1A
