ProcessMeter
How to Get Started
5
How to Get Started
If you are familiar with the Fluke 80 Series DMM, read
“Using the Current Output Functions,” review the tables
and figures in “Getting Acquainted with the Meter,” and
begin using your meter.
If you are unfamiliar with Fluke 80 Series DMMs, or DMMs
in general, read “Measuring Electrical Parameters” in
addition to the sections referenced in the previous
paragraph.
The sections following “Using the Current Output
Functions” contain information about the power-up
options, and battery and fuse replacement instructions.
Later, use the Quick Reference Card to refresh your
memory about the various functions and features that you
can use.
OFF
A
mA
COM
V
1000V
30mA
FUSED
0.44A
(1A/30 sec)
FUSED
mA
mA
A
mA
OUTPUT 0-24mA
SOURCE SIMULATE
+ +
% STEP COARSE FINE
mV
V
V
OUTPUT
CAT
787
PROCESSMETER
MIN MAX RANGE HOLD
H
REL Hz
Display
Pushbuttons
Rotary
Switch
Input/Output
Jacks
ee014f.eps
Figure 1. Fluke 787 ProcessMeter
