ProcessMeter
Getting Acquainted with the Meter
15
Table 6. Display
No. Element Meaning
A Percentage display
Shows the mA measured value or output level in %, in a 0-20 mA or 4-20 mA scale
(change scales with power-up option)
B OUTPUT
Lights when mA output (source or simulate) is active
C D
Lights in diode test function
D S
Lights in continuity function
E Q
Lights when relative reading is on
F B
Lights when the battery is low
G Numerals
Show the input or output value
H H
Lights when TouchHold is on
I MINMAXAVGR
MIN MAX recording status indicators:
MIN means the display is showing the minimum recorded value.
MAX means the display is showing the maximum recorded value.
AVG means the display is showing the average value since starting recording (up to
about 35 hours continuous recording time).
Rmeans MIN MAX recording is on.
