Fluke ProcessMeter 787 - Page 43

ProcessMeter
Specifications
39
Ohms Measurement
Range Resolution Measurement Current Accuracy, ±(% of Reading + Counts)
400.0Ω 0. 1Ω 220 µA 0.2% + 2
4.000 kΩ 0.001 kΩ 59 µA 0.2% + 1
40.00 kΩ 0.01 kΩ 5.9 µA 0.2% + 1
400.0 kΩ 0.1 kΩ 590 nA 0.2% + 1
4.000 MΩ 0.001 MΩ 220 nA 0.35% + 3
40.00 MΩ 0.01 MΩ 22 nA 2.5% + 3
Overload protection: 1000V
Open circuit voltage: <3.9V
