Fluke ProcessMeter 789 User Manual

ProcessMeter
Getting Acquainted with the Meter
13
Table 6. Pushbuttons
No. Pushbutton Function(s)
A
b Toggles the backlight (low, high, and off)
B
Span Check
E
mA Output: Adjusts mA output to 0 % value (4 mA or 0 mA)
C
F
Span Check
mA Output: Sets mA output to 100 % value (20 mA)
D
X
M
% STEP
Measuring: Selects a MIN, MAX, or AVG action
mA Output: Adjusts mA output up to the next higher 25 % step
E
X
R
COARSE
Measuring: Selects a fixed range (hold for 1 second for auto range)
mA Output: Adjusts output up 0.1 mA
F
X
H
FINE
Measuring: Toggles AutoHold, or in MIN MAX recording, suspends recording
mA Output: Adjusts output up 0.001 mA

Fluke ProcessMeter 789 Specifications

General

Diode test	Yes
Frequency range	0 - 19.999 kHz
AC current range	0 - 1 A
AC voltage range	0 - 1000 V
Resistance range	0 - 40000000 Ω
Resolution (AC voltage)	0.1 mV
Dimensions (WxDxH)	100 x 203 x 50 mm

Weight and Dimensions

Weight	610 g
