Getting Acquainted with the Meter
17
Table 7. Display (cont.)
No. Element
Meaning
M mA, DC, mV, AC,
M or kΩ, kHz
Show the input or output units and multipliers associated with the numerals
Auto Range
Manual Range
Range status indicators:
Auto Range - autoranging is on
Manual Range - the range is fixed
N
400100030
mV
The number plus the unit and multiplier indicate the active range.
O mo np
One of these lights in mA ramping or step output (rotary function switch position
Ymonp):
m - slow continuous 0 % - 100 % - 0 % ramping (40 seconds)
o - fast continuous 0 % - 100 % - 0 % ramping (15 seconds)
n - slow ramp in 25 % steps (15 seconds/step)
p - fast ramp in 25 % steps (5 seconds/step)
P 250 Ω
HART
Lights when 250 Ω series resistance is switched in
Q Loop Power
Lights when in loop supply mode

Fluke ProcessMeter 789 Specifications

General

Diode test	Yes
Frequency range	0 - 19.999 kHz
AC current range	0 - 1 A
AC voltage range	0 - 1000 V
Resistance range	0 - 40000000 Ω
Resolution (AC voltage)	0.1 mV
Dimensions (WxDxH)	100 x 203 x 50 mm

Weight and Dimensions

Weight	610 g
