Fluke ProcessMeter 789 User Manual

789
Users Manual
32
Replacing the Batteries
! Warning
To avoid electrical shock:
• Remove test leads from the meter before
opening the battery door.
• Close and latch the battery door before
using the meter.
Replace the batteries as follows. Refer to Figure 11. Use
four AA alkaline batteries.
1. Remove the test leads and turn the meter OFF.
2. With a standard blade hand screwdriver, turn each
battery door screw counterclockwise so that the slot is
parallel with the screw picture molded into the case.
3. Lift off the battery door.
4. Remove the meter’s batteries.
5. Replace with four new AA alkaline batteries.
6. Reinstall the battery door and tighten screws.

Fluke ProcessMeter 789 Specifications

General

Diode test	Yes
Frequency range	0 - 19.999 kHz
AC current range	0 - 1 A
AC voltage range	0 - 1000 V
Resistance range	0 - 40000000 Ω
Resolution (AC voltage)	0.1 mV
Dimensions (WxDxH)	100 x 203 x 50 mm

Weight and Dimensions

Weight	610 g
