Fluke ProcessMeter 789 User Manual

ProcessMeter
Replacement Parts and Accessories
37
Table 13. Replacement Parts
Item Number
Reference
Designator Description Fluke PN or Model no. Quantity
A MP14 Knob Assembly 658440 1
B MP1 Top Case with Lens Protector 1622855 1
C MP8 Decal, Top Case 1623923 1
D MP6 Keypad 1622951 1
E MP5 Top Shield 1622924 1
F MP47 Top Shield Contact 674853 1
G MP4 Contact Housing 1622913 1
H MP28-31 RSOB Contact 1567683 4
I ! F1, F2 Fuse, 440 mA, 1000 V fast-blow 943121 2
J H7,8 PCB Screw 832220 2
K MP9 Bottom Shield 1675171 1
L MP12 IR Lens 658697 1
M MP40,41 LCD Connectors, Elastomeric 1641965 2
N MP7 Backlight/Bracket 1622960 1
O P1 LCD Display 1883431 1
P MP3 Mask 1622881 1

Fluke ProcessMeter 789 Specifications

General

Diode test	Yes
Frequency range	0 - 19.999 kHz
AC current range	0 - 1 A
AC voltage range	0 - 1000 V
Resistance range	0 - 40000000 Ω
Resolution (AC voltage)	0.1 mV
Dimensions (WxDxH)	100 x 203 x 50 mm

Weight and Dimensions

Weight	610 g
