Fluke PTi120 - Product Familiarization; Features; Controls and Connections

PTi120
Users Manual
2
Product Familiarization
Use Table 1 to identify the features of your Product.
Features
Table 1 lists the features of the Product.
Controls and Connections
Table 2 shows the controls and connections of the Product.
Table 1. Features
IR-Fusion Technology Image annotations
Visible Asset Identification
Fullscreen IR Autoblend Fluke Connect desktop software
Table 2. Controls and Connections
Item Description Item Description

LCD touch screen (display)
G
Hand strap

Image capture button
H
LED torch/flashlight

Fluke Connect indicator
I
Infrared camera lens
D
Power button
J
Visual light camera lens
E
USB port
K
USB cable
F
Connector cover
1 2
3
4
5
7
11
8
10
9
6
PTi120
POCKET THERMAL
IMAGER
