Electrosurgery Analyzer
Product Familiarization
7
Table 2. Controls and Connections
Item Description
Footswitch connections: CUT, COAG, COMMON
CQM connection for the Contact Quality Monitor test
Load connections: VARIABLE HI, VARIABLE LO, FIXED
LCD
Rotary selector knob
USB Device port
Function keys (F1 through F5)
BACK key
Scope out
Mains power connection and On/Off switch
Bumpers to protect back panel
Ground lug
