T5-600/T5-1000
Electrical Tester
4
General Specifications (continued)
Shock, Vibration 1 m drop at 15 °C to 35 °C (59 °F to 95 °F) per ANSI/ISA-S82.01-1994 and EN 61010-1 1993.
Sinusoidal vibration per MIL-PRF-28800F for a Class 2 instrument
(5 Hz to 55 Hz, 3 g maximum)
Surge Protection T5-600: 6 kV per IEC 1010-1, 1990-09: T5-1000: 8 kV per IEC 1010-1, 1990-09
Enclosure Rating IP 52 per IEC 60529, no vacuum applied
RF Field Specification 0.5 % full scale + (specified accuracy) at 3 V/m
Safety Complies with ANSI/ISA-S82.01-94 for use in overvoltage category III (CAT III) locations,
UL3111, CSA/CAN C22.2 No.1010.1-92, and EN61010-1 1993.
EMC EN 50081-1, EN 50082-1
Certifications
Resolution and Accuracy
Function T5-600 Range T5-1000 Range Resolution Accuracy
K 600 V rms 1000 V rms 1 V ±(1.5 % + 2 digits)
L 600 V 1000 V 1 V ±(1 % + 1 digit)
? 100.0 A 100.0 A 0.1 A ±(3 % + 3 digits)
e 1000 Ω 1000 Ω 1 Ω±(1 % + 2 digits)
Input Characteristics
Input Protection
Function T5-600 T5-1000
Input impedance (nomial
K
600 V rms 1000 V rms 1 MΩ, <100 pF ac-coupled
L
600 V rms 1000 V rms 1 MΩ, <100 pF
e
600 V rms 1000 V rms
Open Circuit Test Voltage Short Circuit Current
e 2.4 V dc (nominal) <600 µA
CAT III protects against transients in a fixed equipment installation such as a distribution panel, and lighting systems in
large buildings.
CAT IV protects against transients from a primary supply such as an electricity meter or an overhead or underground utility
service.
Cleaning the Tester
WWarning
To avoid electric shock or damage to the tester, never allow water inside the
case. To avoid damaging the tester’s case, never use solvents on the tester.
If the tester requires cleaning, wipe it down with a cloth that is lightly dampened with water or a mild
detergent. Do not use aromatic hydrocarbons, chlorinated solvents, or methanol-based fluids when wiping
down the tester.
