Fluke T5-1000 User Manual

Service Information
Battery Replacement
9
Table 6. Replacement Parts and Accessories (continued)
Description Fluke Part Number
T5-600/T5-1000 Electrical Tester Instruction Sheet (International) 1621978
H5 Belt Holster Accessory
TP1 Probe Set, Flat Blade
Accessory
TP4 Probe Set, 4 mm Round
Accessory
Battery Replacement
Figure 2 shows how to replace the batteries. Observe the polarity markings inside the battery compartment.
qp1.eps
Figure 2. Replacing the Batteries
w ww. . com
information@itm.com1.800.561.8187

Fluke T5-1000 Specifications

General

Safety Rating	CAT III 1000 V, CAT IV 600 V
Display Type	Digital
Continuity Beeper	Yes
OpenJaw Current Measurement	Yes
Resistance Measurement Range	1000 Ω
Dimensions	203 x 51 x 30 mm (8.0 x 2.0 x 1.2 in)
