Fluke T5-600 Instruction Sheet

Measuring Voltage (V)
The tester automatically selects dc (DC) or ac (AC) voltage mode
based on the peak values of the measured signal.
The tester defaults to ac voltage when turned on.
DC Voltage
T5-600 maximum: 600 V
T5-1000 maximum: 1000 V
CAT III
AC Voltage
45 Hz to 66 Hz
T5-600 maximum: 600 V rms
T5-1000 maximum: 1000 V rms
CAT III
DC
AC
V
AC/DC
Automatic
Selection
V
AC/DC
Automatic
Selection
ex2.eps
Measuring Continuity and Resistance (Ω)
Continuity Resistance
1000 Ω
Range
Greater than
400 Ω
Open Short
Less than
25 Ω
ex3.eps
Beeper indicates shorts lasting 1 ms (1/1000 second) or longer.

Fluke T5-600 Specifications

General

Waterproof	Yes
Product type	Digital multimeter
AC current range	0 - 100 A
AC voltage range	0 - 600 V
Resistance range	0 - 1000 Ω
Battery voltage	1.5 V
Dimensions (WxDxH)	30.5 x 51 x 203 mm

Weight and Dimensions

Weight	300 g
