Fluke T5-600 Instruction Sheet

Maintenance
Clean the case with a damp cloth and detergent. Do not use
abrasives or solvents.
Because the inputs are electronically protected, no fuses are
required.
Battery Replacement
Observe the polarity markings inside the battery compartment.
+
+
Do not
overtighten screw
Disconnect probes
from Voltage
Switch OFF
2 AA
+
+
ex4.eps
Replacement Parts
Test Lead Assembly.
Replace only with Fluke double-insulated leads
(
T)
See "Accessories" for available probes.
PN 648029
Battery Door PN 648144
Battery Door Screw PN 643830
Accessories
H5 Belt Holster
TP1 Probe Set, Flat-Blade
TP4 Probe Set, 4 mm round
Service Information Sheet , PN 686953
To contact Fluke, call:
USA and Canada: 1-888-99-FLUKE (1-888-993-5853)
Europe: +31 402-678-200
Japan: +81-3-3434-0181
Singapore: +65-276- 6196
Anywhere in the world: +1-425-446-5500
Visit Fluke’s Web site at www.fluke.com.
Specifications
Calibration: One-year calibration cycle.
Maximum Voltage Between any Terminal and Earth Ground:
T5-600: 600 V rms, Overvoltage Category III;
T5-1000: 1000 V rms, Overvoltage Category III
Temperature: Operating: -10 °C to +50 °C (14 °F to 122 °F);
Storage: -30 °C to +60 °C (-22 °F to +140 °F)
Altitude: Operating: 2000 m (6562 ft); Storage: 10,000 m
(32808 ft)
Relative Humidity: 0 % to 95 %, 5 °C to 30 °C (41 °F to 86 °F);
0 % to 75 %, 30 °C to 40 °C (86 °F to 104 °F);
0 % to 45 %, 40 °C to 50 °C (104 °F to 122 °F)

Fluke T5-600 Specifications

General

Waterproof	Yes
Product type	Digital multimeter
AC current range	0 - 100 A
AC voltage range	0 - 600 V
Resistance range	0 - 1000 Ω
Battery voltage	1.5 V
Dimensions (WxDxH)	30.5 x 51 x 203 mm

Weight and Dimensions

Weight	300 g
