Mains SUBCAB 7GX SUBCAB 4GX SUBCAB AWG SUBCAB Screened
Yellow / Green Yellow / Green Yellow / Green Screen from leads
Groundcheck (GC) - - Yellow -
Colors and marking of the control leads
Mains SUBCAB 7GX and
SUBCAB 4GX
SUBCAB AWG SUBCAB Screened
T1 White T1 Orange White T1
T2 White T2 Blue White T2
T3 - - White T3
T4 - - White T4
Colors of the stator leads
Stator connection Lead color
U1 Red
U2 Green
U5 Red
U6 Green
V1 Brown
V2 Blue
V5 Brown
V6 Blue
W1 Yellow
W2 Black
W5 Yellow
W6 Black
Installation
2125 Installation, Operation, and Maintenance Manual 21
