Mod. B4600Humid
Example of equipment placement without nearby heat sources.
1
Placement of the equipment near heat sources.
1
We recommend leaving a free working space of around 500 mm for maintenance operations.
The device is not suitable for built-in installation.
1
The image shown in this diagram is of a generic type. The external appearance of the device may not correspond to the one purchased.
Min. 100mm
Min. 700mm
Fireproof
insulation panel
Min. 120mm
Min. 120mm
