Main wing installation
4
Model assembly
EN
1.Align and slide the wing spar into the fuselage.
2.Press the left and right door covers down to the bottom (i.e.
closed position) and attach the left and right wings with
landing gear to the fuselage.
NOTE:The connectors on both sides should be attached
precisely and firmly.
3.Secure the wings on the fuselage using the included
screws (HKM3.0*10mm x 6) as shown.
HKM3.0*10mm
