Physical and Electrical Characteristics
Analogue Inputs 1 & 2
Connectors
Neutrik XLR Combo: Mic/Line/Inst (Inputs 1-2)
on front panel
Mic/Line switching Automatic
Line/Instrument switching 2 x front panel switches
Phantom power
Shared +48 V phantom power switch for inputs
1 & 2
Analogue Outputs
Main outputs
2 x balanced ¼” TRS jacks on rear panel (Main
outputs)
Stereo headphone output ¼” TRS jack on front panel
Main output level control
On front panel
Headphones level control
Other I/O
USB 1 x USB 2.0 Type B connector
Front Panel Indicators
USB power & connected LED
Gain controls Colour-coded LED rings
Weight and Dimensions
W x H x D 175 mm x 45 mm x 100 mm
Weight 0.5 kg
