Fohhn Linea Live I User Manual

This equipment conforms to standards EN 61000-6-1, EN 61000-6-3 and EN 60065
We reserve the right to alter the specifications without notice.
38 | Linea Live
Sub XSP-3
Elektroakustische
Akustik Design vented design
Bestückung 1x 15“ long excursion, neodym
Belastbarkeit 700 W
SPL max. 128 dB
Übertragungsbereich 35 Hz – 130 Hz
X)
Lo-Pass-Filter 130Hz / 12dB / Oct.
Hi-Pass-Filter 130Hz / 6dB / Oct.
Impedanz 8 ohms
Sub XSP-2
Elektroakustische
Akustik Design vented design
Bestückung 1x 12“ long excursion, neodym
Belastbarkeit 400 W
SPL max. 125 dB
Übertragungsbereich 38 Hz – 130 Hz
Integrierte passive
Lo-Pass-Filter 130Hz / 12dB / Oct.
Hi-Pass-Filter 130Hz / 6dB / Oct.
Impedanz 4 ohms
Sub active XS-10 / XS-20 / XS-30
Type Sub XSP-10
electro-acoustical features
acoustic design vented design
components 2x 6“ long excursion, neodym
power rating 300 W
SPL max. 120 dB
frequency range 40 Hz – 130 Hz
integrated passive X-over (FX)
lo-pass-filter 130Hz / 12dB / Oct.
hi-pass-filter 130Hz / 6dB / Oct.
nominal impedance 4 ohms
Sub passive XSP-10 / XSP-2 / XSP-3
Sub XS-30 active
electro-acoustical
acoustic design vented design
components 1x 15“ long excursion, Neodym
amplifier output 1.500 W
SPL max. 128 dB
frequency range 35 Hz – 130 Hz
features
enclosure multiply birch wood
protection grille metal, powder coating
standard colour black, textured paint
front design acoustic foam
dimensions (W x H x D) 43 x 59 x 52 cm
weight 29 kg
wheels 2 edge wheels
handles 2 side handle, 2 edge handle
thread plate for M20
optional features
optional colours all RAL-colours
weather resistance scratch-proof plastic coating
Sub XS-20 active
electro-acoustical
acoustic design vented design
components 1x 12“ long excursion, Neodym
amplifier output 1.000 W
SPL max. 125 dB
frequency range 38 Hz – 130 Hz
features
enclosure multiply birch wood
protection grille metal, powder coating
standard colour black, textured paint
front design acoustic foam
dimensions (W x H x D) 43 x 39 x 44 cm
weight 19 kg
wheels -
handles 2 edge handle
thread plate for M20
optional features
optional colours all RAL-colours
weather resistance scratch-proof plastic coating
Type Sub XS-10 active
electro-acoustical features
acoustic design vented design
components 2x 6“ long excursion, Neodym
amplifier output 1.000 W
SPL max. 120 dB
frequency range 40 Hz – 130 Hz
features
enclosure multiply birch wood
protection grille metal, powder coating
standard colour black, textured paint
front design acoustic foam
dimensions (W x H x D) 43 x 25 x 44 cm
weight 12 kg
wheels -
handles 1 edge handle
thread plate for distance piece M20
optional features
optional colours all RAL-colours
weather resistance scratch-proof plastic coating
