Attention – Should local codes require a hard-wired connection and/or shielded wiring, eliminate the
cord and plug(s) and follow the appropriate field wiring diagram on the following page.
See Icemaker Installation and Operation manual for recommended junction box preparation of hard-
wired Satellite-fill icemakers.
6
Field wiring for countertop and wall mount dispensers with Satellite-fill
icemakers
All field wiring must be installed in accordance with NEC and local electrical codes. Field wiring
diagram is intended only to aid electrician or technician in understanding how equipment works.
!
Field wiring for countertop and wall mount dispensers with Satellite-fill
icemakers
Model Electrical connection Circuits required
110FB400A/W cord & plug provided 115/60/1, 20 amp max. fuse size
110CT400A/W cord & plug provided 115/60/1, 20 amp max. fuse size
110CR400A/W cord & plug provided 115/60/1
dispenser: 20 amp max. fuse size
ice maker: 20 amp max. fuse size
!
