6 Horizon 1400R/N Ice Machines
Dimensions and clearances
Entire front of ice machine must be clear of obstructions/connections to allow removal.
1" (26 mm) clearance above ice machine for service.
1" (26 mm) minimum clearance on sides.
36.25"
(921 mm)
25.5"
(648 mm)
26.08"
(662 mm)
Condensing Unit
Back ViewSide ViewFront View
right angle
5 5-1ANEM
L1
L2
G
23.77" (604mm)
Air exhaust
both sides
21.28" (541mm)
23.50"
(597mm)
21.05" (535mm)
3/4" MPT drain
(46mm)
1. 81
(73mm)
2.87
(368mm)
14.47"
(177mm)
6.95"
(65mm)
2.53"
15.69" (399mm)
2.5" (64mm)
19.3" (491mm)
Ice transport tube connection
3/8" liquid line
5/8" suction line
3/8" OD push-in
water inlet
