Once the device stand is mounted, the upper foam layer with the accessories may be lifted out of
the box, thereby revealing the lambda.7 haptic device controller, as shown in figure 6.
Figure 6 – Shipping box containing the lambda.7 device after removal of the upper foam layer.
Place the upper foam layer upside down on a flat surface.
Carefully extract the haptic device from the carboard box and place the system on its upper foam
layer as shown in figure 8. This will protect the haptic device during preparation.
Finally, remove the protective foam which secures the wrist and gripper handle.
Figure 7 – Lifting the haptic device out of its shipping box.
