Protected componentsFuse amp ratingFuse or relay number

Not used.–86

Anti-lock brake system pump.

60A

M-type fuse.

J-type fuse.

Passenger Compartment Fuse

Panel

The fuse panel is located under the

instrument panel to the left of the steering

column.

Note: It may be easier to access the fuse

panel if you remove the finish trim piece.

E145984

Protected componentsFuse amp ratingFuse or relay number

Demand lighting (glove box, vanity, dome).

10A

Battery saver relay coil.

254
