Drivebelt Routing

2.7L EcoBoost engine

E191903

ENGINE SPECIFICATIONS - 3.5L

3.5L engineEngine

214Cubic inches

Minimum 87 octaneRequired fuel

10.8:1Compression ratio

.049-.053 in. (1.25 - 1.35 mm)Spark plug gap

Drivebelt Routing

3.5L engine

E191904
