DescriptionItemCallout
Represents your high-voltage battery. A
circle illuminates around the node when
the high-voltage battery is receiving power
from regenerative braking or engine char-
ging. The higher the power going into the
high-voltage battery, the larger the circle
around this node.
High Voltage Battery PowerG
Represents the fuel tank in the vehicle.FuelH
Shows flow from the fuel tank to the
engine when the engine is on and using
fuel (there are some cases where the
engine is on, but not using any fuel). When
the engine is on, but not using fuel, the
engine node is active, but the fuel flow
path is off. An example of this is when your
foot is off the accelerator pedal and the
vehicle is traveling at a high speed.
Fuel-to-Engine FlowI
Provides you with the reason(s) the
gasoline engine is on. When the gasoline
engine is off, this display does not appear.
Engine On due to reasons displayed by
the system are in a chart following this list.
Engine On due to:J
Shows the direction of power flow
between the engine and the electric motor.
The direction indicates if the engine is
providing power to the high-voltage elec-
trical system, or if the high-voltage elec-
trical system is providing power to control
or start the engine.
Motor-to-Engine FlowK
79
MKC (TME) , enUSA, Edition date: 01/2016, Second Printing
SYNC™ 3
