Introduction | 7
2.2 Technical specifications
Parameter Unit
Printer Form 3BL
3D printing technology Low Force Stereolithography (LFS)™
Minimum dimensions for convenient
access (W × D × H)
90 × 96 × 104 cm | 35.4 × 37.8 × 41 in
Printer dimensions (W × D × H) 77 × 52 × 74 cm | 30.3 × 20.5 × 29.1 in
Printer weight 54.4 kg | 120 lb
Build volume (W × D × H) 33.5 × 20 × 30 cm | 13.2 × 7.9 × 11.8 in
Layer thickness (Axis resolution) 25–300 microns | 0.001–0.012 in
XY resolution 25 microns | 0.001 in
Laser spot size (FWHM) 85 microns | 0.0033 in
Resin cartridges 2
Resin dispensing system Automated
Biocompatible materials No
Supports Auto-generated, Light-touch removal
Operating environment 18–28 °C | 64–82 °F
Low ambient humidity
Operating temperature Auto-heats to 35 °C | 95 °F
Temperature control Air heated print chamber
Power requirements 100–240 VACMaximum 8.5 A
50/60 Hz
650 W
Laser specifications IEC 60825-1:2014 | EN 60825-1:2014
Class 1 laser product
2 Light Processing Units (LPUs)
In each Light Processing Unit (LPU):
405 nm violet laser | Maximum 250 mW
Radiation information The Form 3BL is a Class 1 laser product. Accessible radiation
is within Class 1 limits.
Connectivity Wi-Fi: 2.4, 5 GHz
Ethernet: 1000 Mbit
USB: 2.0
Wi-Fi connectivity Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz, 5 GHz
Supported security: WPA/WPA2
Ethernet connectivity RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN Port
Connect with a shielded Ethernet cable (not included):
minimum Cat5, or Cat5e or Cat6 for 1000BASE-T.
USB connectivity USB (rev 2.0) B port with a USB A-B cable
Sound emission Does not exceed 70 dB(A).
Printer control Interactive touchscreen
Alerts Touchscreen alerts, SMS/email via Dashboard,Two LED status
indicators, Speaker for audio alerts
Print preparation PreForm desktop software
File type STL or OBJ
