8
2.3 Product elements
2.3.1 Form 3BL
Resin cartridge: Two containers hold the resin before dispensing into the resin tank. Shake
the resin cartridges periodically to keep resin well mixed.
Cover: The printer lid, made of metal and a strong, orange-tinted material, blocks exposure
to the lasers and protects the resin from curing due to ambient light.
Build platform: The aluminum base provides a surface for prints to attach to.
Resin tank: Resin is dispensed out of the resin cartridges into the resin tank. During a print,
two lasers pass upwards through the flexible film and cure resin onto the build platform
to form a printed part.
Mixer: Each resin tank includes a mixer that improves print consistency by clearing the
build area and circulating the resin.
Touchscreen: The LCD capacitive touch user interface displays print information, settings,
and error messages.
Leveling disc: Slide the leveling disc included around one of the leveling feet and rotate
to raise or lower the printer.
Status light: Two interior lights (vertical strips along the left and right walls) and an
illuminated logo (on the front panel) that pulse to indicate the printer is active, a print has
completed, or the printer has encountered an error.
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
