Form Wash automatically cleans uncured liquid resin
from 3D printed parts’ surfaces.
1 Basket Mount. A single hook secures the basket to raise and lower.
2 Basket. Holds parts to wash without the build platform.
3 Platform Mount. Holds the build platform when washing parts.
4 Outer Lid. Limits IPA evaporation. Keep the lid closed when not in use.
5 Inner Lid. A hinged, secondary lid opens and closes to contain IPA
while allowing parts to be lowered or raised from the bucket.
6 Wash Bucket. The removable container holds a maximum of 8.6 L
of IPA. A rotating impeller at the bottom circulates IPA.
7 Display. Shows status, time, and options for configuring Form Wash.
8 Knob. Turn or push to adjust time and to start, pause, or end a wash cycle.
9 Tool Storage. Each side has designated locations for storing each tool.
10 Power Supply. Provides power to Form Wash. Specifications: 24 V, 2 A
11 Isopropyl Alcohol (IPA). Not included. Dissolves liquid resin from printed
parts’ surfaces. Start with 10 L. Concentration must be 90% or higher.
FORM WASH SYSTEM OVERVIEW
