Formula Fastech - DIMENSIONS

3-2
FORMULA
FASTECH
FASTECH
DIMENSIONS
E
B
C
D
A
FOR186
A
B
C
D
E
F
Maximum Beam
Centerline Length
Bridge Clearance - Dry
Draft - Drive Unit Up
Draft - Drive Unit Down
Dead Rise
271 Fastech
8'3" (2.5 m)
27'1" (8.3 m)
4'11" (1.5 m)
31" (78.7 cm)
34" (86 cm)
24°
292 Fastech
8'3" (2.5 m)
29'2" (8.9 m)
4'11" (1.5 m)
30" (76.2 cm)
33" (84 cm)
24°
353 Fastech
8'3" (2.5 m)
35'3" (10.7 m)
5'4" (1.6 m)
33" (84 cm)
36" (91 cm)
24°
382 Fastech
8'3" (2.5 m)
38'2" (11.6 m)
5'6" (1.6 m)
30" (76.2 cm)
33" (84 cm)
24°
