WWW.FORNEYIND.COM
17
TORCH PARTS LIST
TORCH PARTS BREAKDOWN
23010083 PT-25C PLASMA TORCH WITH 13’ LEAD
01 23015183 PLASMA TORCH BODY 1
02 23015187 ELECTRODE 1
03 23015179 AIR DISTRIBUTION RING 1
04 23015189 TIP ø 0,65 / .025 1
05 23015182 SHIELD CUP 1
06 23015193 WRENCH FOR ELECTRODE 1
07 23015184 COMPLETE HANDLE 1
08 23015195 CABLE ASSEMBLY 1
To Next Page
