74
WWW.FORNEYIND.COM
Diagrama de cableado
VERDE
FUSIBLE
ENERGÍA EN LA LÁMPARA DEL
PILOTO
VENTILADOR
RECTIFICADOR
INTERRUPTOR ON-OFF
(ENCENDIDO/APAGADO)
OBTURADOR
TRANSFORMADOR
