Fortinet 40D - Page 20

20
1
2
4
5
6
1. SIM1, SIM2
PCIe ports for primary and
secondary 3G/4G LTE SIM cards.
2. USB
Reserved for future use.
4. Power
12V DC, 1.25A power
adapter connection.
Optional.
5. LAN/POE
RJ-45 port, 10/100/1000
Ethernet, PoE-PD
enabled, 802.3af/at
compliant, (15.4W).
6. Console
RJ-45 port
FEX-40D
3
3. Reset Button
Press and hold to reset
the system to the factory
defaults
