FortiGate-1000 Administration Guide Version 2.80 MR6

FortiGate-1000 Administration Guide 01-28006-0009-20041105 247

VPN

FortiGate units support the following protocols to authenticate and encrypt traffic:

• Internet Protocol Security (IPSec)

• Point-to-Point Tunneling Protocol (PPTP)

• Layer Two Tunneling Protocol (L2TP)

This chapter contains information about the following VPN topics:

• Phase 1

• Phase 2

• Manual key

• Concentrator

• Ping Generator

• Monitor

• PPTP

• L2TP

• Certificates

• CLI configuration

• Authenticating peers with preshared keys

• Gateway-to-gateway VPN

• Dialup VPN

• Dynamic DNS VPN

• Manual key IPSec VPN

• Adding firewall policies for IPSec VPN tunnels

• Internet browsing through a VPN tunnel

• IPSec VPN in Transparent mode

• Hub and spoke VPNs

• Redundant IPSec VPNs

• Configuring IPSec virtual IP addresses

• Troubleshooting
